DBI

Recent developments in R’s database interface

Kirill Müller, @krlmlr

2018-09-03, R meetup Zurich, https://bit.ly/2wFJix3

1 / 63

(Commercial)2 / 63

adminR: R in Swiss Official Statistics

R users in Swiss public adminis-tration, or institutions with ties to it

Get to know each other
Share our experience
Learn about different use cases of R in public statistics

Thursday, September 20, 2018
5:15 PM to 7:15 PM

State Secretariat for Economic Affairs

SECO · Holzikofenweg 36 · Bern

(Commercial)

3 / 63

Who has ...

via GIPHY

4 / 63

Hi! Welcome everybode to my presentation.

Today I'll talk about R and databases.

Before we start, I'd like to conduct a short survey.

... worked with R?5 / 63

... used a data frame (or tibble) in R?6 / 63

... worked with a database?7 / 63

A separate server whose only purpose is to store and retrieve data.

... written a SQL query?8 / 63

... or "an Ess-Cue-Ell query"?

... connected to a database from R?9 / 63

to retrieve some data

... connected to a database from Rusing DBI ?10 / 63

Did your code use dbConnect() ?

... defined a database schema?11 / 63

If you don't know what a schema is, you probably haven't. But I'll talk about it later.

... implemented a DBI backend?12 / 63

If you don't know what a DBI backend is, you probably haven't.

↔

13 / 63

Thanks. Today's presentation will be about connecting relational databases to R using the DBI package. I'd like to make this presentation useful for you, no matter if you're new to databases or if you use them daily. I'm going to start with some basic concepts, but I'm also including more advanced examples.

storage for a set of rectangular tables
- rows and columns, atomic columns
- similar to data frames
"relational": some tables have column with the same meaning (or name), rows from different tables with the same value in these columns are related
databases store their data on disk, optimized for retrieval without reading everything into memory
- Postgres, MySQL/MariaDB, SQLite (open-source)
- Microsoft SQL Server, Oracle (commercial)
No non-relational: Mongo DB or ElasticSearch, see nodbi by Scott
No other solutions such as the RODBC package

Connect to a Postgres database

library(RPostgres)
con <- dbConnect(Postgres())
dbGetQuery(con, "SELECT 'Hello, world!' AS hi")

##              hi
## 1 Hello, world!

dbDisconnect(con)

14 / 63

This talk will use a lot of code examples, please bear with me.

Explain code line by line
Query string: SQL

Connect to a MariaDB database

library(RMariaDB)
con <- dbConnect(MariaDB())
dbGetQuery(con, "SELECT 'Hello, world!' AS hi")

##              hi
## 1 Hello, world!

dbDisconnect(con)

15 / 63

Mention SQL dialects

Connect to a SQLite database

library(RSQLite)
con <- dbConnect(SQLite())
dbGetQuery(con, "SELECT 'Hello, world!' AS hi")

##              hi
## 1 Hello, world!

dbDisconnect(con)

16 / 63

DataBase Interface

library(DBI)
con <- dbConnect(RSQLite::SQLite())
# con <- dbConnect(RMariaDB::MariaDB())
# con <- dbConnect(RPostgres::Postgres())
dbGetQuery(con, "SELECT 'Hello, world!' AS hi")

##              hi
## 1 Hello, world!

dbDisconnect(con)

17 / 63

Not only syntactic similarity

Attach DBI instead of individual database packages, only specify database in dbConnect()

Use only functions from DBI to work with the database, only refer to database backends when connecting.

S4 classes and methods
method = function defined in DBI

18 / 63

What is a DBI backend?

More packages involved, omitted here

ODBC is covered as part of this framework

Extra packages

DBI: Function definition
Can use database-specific backends

19 / 63

DBI has been around for ages, almost as old as R itself.

Interfaces: syntax vs. semantics20 / 63

DBI 0.x had the "syntax" bit right

Subtle differences in semantics between packages

Data types
- 64-bit integers
Character encoding
Time zones
Behavior in corner cases (zero rows)
Optional syntax

21 / 63

DBI specification

Implementers

Test suite

Clear expectations

Boilerplate

Users

Interchangeable backends

Reliable behavior

Precise documentation

22 / 63

Simplify user's life
- Only learn one interface
Simplify implementer's life
We can't force DBI backends, but we provide a test suite
Project funded by R Consortium
First two parts done

23 / 63

Walk through DBI's features
- Pointing to new features
Showcase interesting developments

R's DataBase Interface

connect/disconnect

discover

read/write

query/execute

quote/parametrize

transact

24 / 63

Connecting

via GIPHY

25 / 63

First step when working with a database

Can be frustrating when things don't work, but needs to be done only once

Only thing that is backend-specific: connection parameters

library(DBI)
con_sqlite <- dbConnect(
  RSQLite::SQLite(),
  path = "..."
)
con_mariadb <- dbConnect(
  RMariaDB::MariaDB(),
  default.file = "..."
)
con_postgres <- dbConnect(
  RPostgres::Postgres(),
  host = "...",
  port = "..."
)
dbDisconnect(con_postgres)
dbDisconnect(con_mariadb)
dbDisconnect(con_sqlite)

26 / 63

27 / 63

Discovering

via GIPHY

28 / 63

library(DBI)
con <- dbConnect(RPostgres::Postgres())
dbListTables(con)

## [1] "geography_columns" "geometry_columns"  "spatial_ref_sys"
## [4] "raster_columns"    "raster_overviews"  "topology"
## [7] "layer"             "geom_test"         "temp"

29 / 63

dbListObjects(con)

##                               table is_prefix
## 1    <Id> table = geography_columns     FALSE
## 2     <Id> table = geometry_columns     FALSE
## 3      <Id> table = spatial_ref_sys     FALSE
## 4       <Id> table = raster_columns     FALSE
## 5     <Id> table = raster_overviews     FALSE
## 6             <Id> table = topology     FALSE
## 7                <Id> table = layer     FALSE
## 8            <Id> table = geom_test     FALSE
## 9                 <Id> table = temp     FALSE
## 10           <Id> schema = topology      TRUE
## 11          <Id> schema = my_schema      TRUE
## 12 <Id> schema = information_schema      TRUE
## 13         <Id> schema = pg_catalog      TRUE
## 14       <Id> schema = nycflights13      TRUE
## 15             <Id> schema = public      TRUE

30 / 63

Schema: like a directory in the file system

flights_obj <- dbListObjects(con, Id(schema = "nycflights13"))
flights_obj

##                                          table is_prefix
## 1 <Id> schema = nycflights13, table = airlines     FALSE
## 2 <Id> schema = nycflights13, table = airports     FALSE
## 3  <Id> schema = nycflights13, table = flights     FALSE
## 4   <Id> schema = nycflights13, table = planes     FALSE
## 5  <Id> schema = nycflights13, table = weather     FALSE

flights_obj$table[[3]]

## <Id> schema = nycflights13, table = flights

31 / 63

32 / 63

Reading

via GIPHY

33 / 63

spatial_ref_sys <- dbReadTable(con, "spatial_ref_sys")
class(spatial_ref_sys)

## [1] "data.frame"

tibble::as_tibble(spatial_ref_sys)

## # A tibble: 5,435 x 5
##     srid auth_name auth_srid srtext            proj4text
##    <int> <chr>         <int> <chr>             <chr>
##  1  3819 EPSG           3819 "GEOGCS[\"HD1909… "+proj=longlat +e…
##  2  3821 EPSG           3821 "GEOGCS[\"TWD67\… "+proj=longlat +e…
##  3  3824 EPSG           3824 "GEOGCS[\"TWD97\… "+proj=longlat +e…
##  4  3889 EPSG           3889 "GEOGCS[\"IGRS\"… "+proj=longlat +e…
##  5  3906 EPSG           3906 "GEOGCS[\"MGI 19… "+proj=longlat +e…
##  6  4001 EPSG           4001 "GEOGCS[\"Unknow… "+proj=longlat +e…
##  7  4002 EPSG           4002 "GEOGCS[\"Unknow… "+proj=longlat +e…
##  8  4003 EPSG           4003 "GEOGCS[\"Unknow… "+proj=longlat +e…
##  9  4004 EPSG           4004 "GEOGCS[\"Unknow… "+proj=longlat +e…
## 10  4005 EPSG           4005 "GEOGCS[\"Unknow… "+proj=longlat +a…
## # ... with 5,425 more rows

34 / 63

This presentation is a "pure" presentation

flights <- dbReadTable(
  con,
  Id(schema = "nycflights13", table = "flights")
)
tibble::as_tibble(flights)

## # A tibble: 336,776 x 19
##     year month   day dep_time sched_dep_time dep_delay arr_time
##    <int> <int> <int>    <int>          <int>     <dbl>    <int>
##  1  2013     1     1      517            515         2      830
##  2  2013     1     1      533            529         4      850
##  3  2013     1     1      542            540         2      923
##  4  2013     1     1      544            545        -1     1004
##  5  2013     1     1      554            600        -6      812
##  6  2013     1     1      554            558        -4      740
##  7  2013     1     1      555            600        -5      913
##  8  2013     1     1      557            600        -3      709
##  9  2013     1     1      557            600        -3      838
## 10  2013     1     1      558            600        -2      753
## # ... with 336,766 more rows, and 12 more variables:
## #   sched_arr_time <int>, arr_delay <dbl>, carrier <chr>,
## #   flight <int>, tailnum <chr>, origin <chr>, dest <chr>,
## #   air_time <dbl>, distance <dbl>, hour <dbl>, minute <dbl>,
## #   time_hour <dttm>

35 / 63

Querying

via GIPHY

36 / 63

query <- 'SELECT * FROM "nycflights13"."flights" WHERE month = 1'
flights <- dbGetQuery(con, query)
dim(flights)

## [1] 27004    19

37 / 63

Quoting

via GIPHY

38 / 63

Quoting identifiers and literals

Dynamic SQL

Evil code!

month <- 1
query <- paste0(
  'SELECT * FROM "nycflights13"."flights" WHERE month = ',
  month
)
cat(query)

## SELECT * FROM "nycflights13"."flights" WHERE month = 1

39 / 63

month <- 1
query <- paste0(
  'SELECT * FROM "nycflights13"."flights" WHERE month = ',
  dbQuoteLiteral(con, month)
)
cat(query)

## SELECT * FROM "nycflights13"."flights" WHERE month = 1::float8

40 / 63

month_var <- "month"
month <- 1
query <- paste0(
  'SELECT * FROM "nycflights13"."flights" WHERE ',
  month_var,
  ' = ',
  dbQuoteLiteral(con, month)
)
cat(query)

## SELECT * FROM "nycflights13"."flights" WHERE month = 1::float8

41 / 63

month_var <- "month"
month <- 1
query <- paste0(
  'SELECT * FROM "nycflights13"."flights" WHERE ',
  dbQuoteIdentifier(con, month_var),
  ' = ',
  dbQuoteLiteral(con, month)
)
cat(query)

## SELECT * FROM "nycflights13"."flights" WHERE "month" = 1::float8

42 / 63

table_name <- Id(schema = "nycflights13", table = "flights")
month_var <- "month"
month <- 1
query <- paste0(
  'SELECT * FROM ',
  dbQuoteIdentifier(con, table_name),
  ' WHERE ',
  dbQuoteIdentifier(con, month_var),
  ' = ',
  dbQuoteLiteral(con, month)
)
cat(query)

## SELECT * FROM "nycflights13"."flights" WHERE "month" = 1::float8

flights <- dbGetQuery(con, query)
dim(flights)

## [1] 27004    19

43 / 63

Much more interesting when quoting strings, datetime, ...

table_name <- Id(schema = "nycflights13", table = "flights")
month_var <- "month"
month <- 1
query <- paste0(
  'SELECT * FROM ',
  dbQuoteIdentifier(con, table_name),
  ' WHERE ',
  dbQuoteIdentifier(con, month_var),
  ' = $1'
)
cat(query)

## SELECT * FROM "nycflights13"."flights" WHERE "month" = $1

flights <- dbGetQuery(
  con,
  query,
  params = list(1)
)
dim(flights)

## [1] 27004    19

44 / 63

via GIPHY

45 / 63

library(dplyr)
library(dbplyr)
src <- src_dbi(con)
flights <- tbl(con, ident_q('"nycflights13"."flights"'))
flights

## # Source:   table<"nycflights13"."flights"> [?? x 19]
## # Database: postgres [kirill@/var/run/postgresql:5432/kirill]
##     year month   day dep_time sched_dep_time dep_delay arr_time
##    <int> <int> <int>    <int>          <int>     <dbl>    <int>
##  1  2013     1     1      517            515         2      830
##  2  2013     1     1      533            529         4      850
##  3  2013     1     1      542            540         2      923
##  4  2013     1     1      544            545        -1     1004
##  5  2013     1     1      554            600        -6      812
##  6  2013     1     1      554            558        -4      740
##  7  2013     1     1      555            600        -5      913
##  8  2013     1     1      557            600        -3      709
##  9  2013     1     1      557            600        -3      838
## 10  2013     1     1      558            600        -2      753
## # ... with more rows, and 12 more variables:
## #   sched_arr_time <int>, arr_delay <dbl>, carrier <chr>,
## #   flight <int>, tailnum <chr>, origin <chr>, dest <chr>,
## #   air_time <dbl>, distance <dbl>, hour <dbl>, minute <dbl>,
## #   time_hour <dttm>

46 / 63

flights %>%
  select(year, month, day, ends_with("delay")) %>%
  filter(month == 2)

## # Source:   lazy query [?? x 5]
## # Database: postgres [kirill@/var/run/postgresql:5432/kirill]
##     year month   day dep_delay arr_delay
##    <int> <int> <int>     <dbl>     <dbl>
##  1  2013     2     1        -4         4
##  2  2013     2     1        -5        -4
##  3  2013     2     1        -3         8
##  4  2013     2     1        -8       -10
##  5  2013     2     1         0         9
##  6  2013     2     1        -8        -1
##  7  2013     2     1        -8         9
##  8  2013     2     1        -8       -14
##  9  2013     2     1        -7        18
## 10  2013     2     1        -7        -4
## # … with more rows

47 / 63

flights %>%
  group_by(year, month, day) %>%
  summarize(mean(arr_delay))

## Warning: Missing values are always removed in SQL.
## Use `AVG(x, na.rm = TRUE)` to silence this warning

## # Source:   lazy query [?? x 4]
## # Database: postgres [kirill@/var/run/postgresql:5432/kirill]
## # Groups:   year, month
##     year month   day `mean(arr_delay)`
##    <int> <int> <int>             <dbl>
##  1  2013     1     1            12.7
##  2  2013     1     2            12.7
##  3  2013     1     3             5.73
##  4  2013     1     4            -1.93
##  5  2013     1     5            -1.53
##  6  2013     1     6             4.24
##  7  2013     1     7            -4.95
##  8  2013     1     8            -3.23
##  9  2013     1     9            -0.264
## 10  2013     1    10            -5.90
## # … with more rows

48 / 63

flights %>%
  group_by(year, month, day) %>%
  summarize(mean_delay = mean(arr_delay, na.rm = TRUE))

## # Source:   lazy query [?? x 4]
## # Database: postgres [kirill@/var/run/postgresql:5432/kirill]
## # Groups:   year, month
##     year month   day mean_delay
##    <int> <int> <int>      <dbl>
##  1  2013     1     1     12.7
##  2  2013     1     2     12.7
##  3  2013     1     3      5.73
##  4  2013     1     4     -1.93
##  5  2013     1     5     -1.53
##  6  2013     1     6      4.24
##  7  2013     1     7     -4.95
##  8  2013     1     8     -3.23
##  9  2013     1     9     -0.264
## 10  2013     1    10     -5.90
## # … with more rows

49 / 63

flights %>%
  group_by(year, month, day) %>%
  summarize(mean_delay = mean(arr_delay, na.rm = TRUE)) %>%
  sql_render()

## <SQL> SELECT "year", "month", "day", AVG("arr_delay") AS "mean_delay"
## FROM "nycflights13"."flights"
## GROUP BY "year", "month", "day"

50 / 63

flights %>%
  group_by(year, month, day) %>%
  summarize(mean_delay = mean(arr_delay, na.rm = TRUE)) %>%
  collect()

## # A tibble: 365 x 4
## # Groups:   year, month [12]
##     year month   day mean_delay
##    <int> <int> <int>      <dbl>
##  1  2013     2     9       6.64
##  2  2013     5    18     -10.7
##  3  2013     8    20      -8.21
##  4  2013     2    24       1.09
##  5  2013     4    27     -12.0
##  6  2013     1    31      32.6
##  7  2013    11    15      -4.68
##  8  2013    11     4       3.46
##  9  2013    10    19      -1.08
## 10  2013    12    19       9.01
## # … with 355 more rows

51 / 63

model <- lm(arr_delay ~ factor(origin) + dep_delay, nycflights13::flights)
summary(model)

##
## Call:
## lm(formula = arr_delay ~ factor(origin) + dep_delay, data = nycflights13::flights)
##
## Residuals:
##      Min       1Q   Median       3Q      Max
## -107.429  -11.042   -1.684    8.804  202.748
##
## Coefficients:
##                     Estimate Std. Error  t value Pr(>|t|)
## (Intercept)       -6.1975535  0.0539274 -114.924  < 2e-16 ***
## factor(origin)JFK -0.5112923  0.0758116   -6.744 1.54e-11 ***
## factor(origin)LGA  1.4919371  0.0773890   19.278  < 2e-16 ***
## dep_delay          1.0196879  0.0007865 1296.428  < 2e-16 ***
## ---
## Signif. codes:  0 '***' 0.001 '**' 0.01 '*' 0.05 '.' 0.1 ' ' 1
##
## Residual standard error: 18.01 on 327342 degrees of freedom
##   (9430 observations deleted due to missingness)
## Multiple R-squared:  0.8372,    Adjusted R-squared:  0.8372
## F-statistic: 5.612e+05 on 3 and 327342 DF,  p-value: < 2.2e-16

52 / 63

library(tidypredict)
sql <- tidypredict_sql(model, con)
sql

## <SQL> -6.19755349842104 + (CASE WHEN ("origin" = 'JFK') THEN (1.0) WHEN NOT("origin" = 'JFK') THEN (0.0) END) * (-0.511292266035181) + (CASE WHEN ("origin" = 'LGA') THEN (1.0) WHEN NOT("origin" = 'LGA') THEN (0.0) END) * (1.49193714231315) + ("dep_delay") * (1.01968794076906)

cat(strwrap(sql), sep = "\n")

## -6.19755349842104 + (CASE WHEN ("origin" = 'JFK') THEN
## (1.0) WHEN NOT("origin" = 'JFK') THEN (0.0) END) *
## (-0.511292266035181) + (CASE WHEN ("origin" = 'LGA') THEN
## (1.0) WHEN NOT("origin" = 'LGA') THEN (0.0) END) *
## (1.49193714231315) + ("dep_delay") * (1.01968794076906)

53 / 63

rquery   Alternative for generating SQL queriesdbx   Useful DML operations (update, upsert, ...)sqlr   Database-agnostic DDLarkdb   Database-agnostic import and exportsf   (Support for spatial databases)bigrquery, civis, MonetDBLite, odbc, RClickhouse, ... (Other backends)... ?54 / 63

ConsistentInterface toWork with databases in R55 / 63

Thank contributors!

FIXME: Word cloud

56 / 63

via GIPHY

57 / 63

Become a contributor today!

con <- RPostgres::Postgres()@connect()
con@get_query("SELECT 'Hello, world!' AS hi")

58 / 63

https://bit.ly/2wFJix3

https://r-dbi.org

@krlmlr

59 / 63

60 / 63

Writing and executing61 / 63

dbWriteTable(con, "spatial_ref_sys", spatial_ref_sys)
dbCreateTable(con, "spatial_ref_sys", spatial_ref_sys)
dbAppendTable(con, "spatial_ref_sys", spatial_ref_sys)

62 / 63

dbExecute(con, "DROP TABLE ...")
dbBegin(con)
dbExecute(con, "UPDATE TABLE ...")
dbExecute(con, "INSERT TABLE ...")
dbCommit(con)
dbWithTransaction(
  con,
  {
    dbExecute(con, "UPDATE TABLE ...")
    dbExecute(con, "INSERT TABLE ...")
  }
)

↑, ←, Pg Up, k	Go to previous slide
↓, →, Pg Dn, Space, j	Go to next slide
Home	Go to first slide
End	Go to last slide
Number + Return	Go to specific slide
b / m / f	Toggle blackout / mirrored / fullscreen mode
c	Clone slideshow
p	Toggle presenter mode
t	Restart the presentation timer
?, h	Toggle this help

DBI

Recent developments in R’s database interface

Kirill Müller, @krlmlr

2018-09-03, R meetup Zurich, https://bit.ly/2wFJix3

(Commercial)

adminR: R in Swiss Official Statistics

(Commercial)

Who has ...

... worked with R?

... used a data frame (or tibble) in R?

... worked with a database?

... written a SQL query?

... connected to a database from R?

... connected to a database from R

using DBI ?

... defined a database schema?

... implemented a DBI backend?

Connect to a Postgres database

Connect to a MariaDB database

Connect to a SQLite database

DataBase Interface

Interfaces: syntax vs. semantics

DBI specification

Implementers

Test suite

Clear expectations

Boilerplate

Users

Interchangeable backends

Reliable behavior

Precise documentation

R's DataBase Interface

connect/disconnect

discover

read/write

query/execute

quote/parametrize

transact

Connecting

Discovering

Reading

Querying

Quoting

rquery Alternative for generating SQL queries

dbx Useful DML operations (update, upsert, ...)

sqlr Database-agnostic DDL

arkdb Database-agnostic import and export

sf (Support for spatial databases)

bigrquery, civis, MonetDBLite, odbc, RClickhouse, ... (Other backends)

... ?

Consistent

Interface to

Work with databases in R

https://bit.ly/2wFJix3

https://r-dbi.org

@krlmlr

Writing and executing

(Commercial)

Help
